TE-139 CNC Narrow Reach Tool Holder Extension 3/4 Shank, 6 Inch Length, 1/2 Inch Inner Dia.
$117.56
Usually ships on the 2nd business day from order date.
| Shank (d) | 3/4 |
|---|---|
| Overall Length (L) | 6 |
| Replacement Screw | 67216 (2) |
| Inner Diameter (id) | 1/2 |
Description
Side Lock with Key
- For use with high precision spring collets
- Precision ground for best Total Indicator Runout (TIR)
- Shank to pocket runout 0.0004″ (0.01mm)
- Black oxide finish for corrosion protection
- Max RPM = 10,000 for safe operation
Specifications
| Shank (d) | 3/4 |
| Overall Length (L) | 6 |
| Replacement Screw | 67216 (2) |
| Inner Diameter (ID) | 1/2 |
