EZ120-24-22EZ120-24-22

EZ120-24-22 EZ Dial Adustable Scoring Set – Shim Free 120mm Dia x 24T 22mm Bore, EZ Dial

$530.25

Usually ships on the 2nd business day from order date.
Diameter (D) 120mm
Teeth 12 x 2
(d) Bore 22mm & 3/4
Kerf (B) (2.8-3.6mm)
Machine Fits most machines including Altendorf®, SCM, Casolin Astra Top, Casadei Shark & Lazzari
You will receive a courtesy discount of 5% if your cart exceeds $100 :)
UPC: 738685224229 SKU: EZ120-24-22 Categories: , ,

Description

Adjustments can easily be made while the scoring set is mounted on the machine! Adjusting the scoring set is quick and easy, simply turn the dial to adjust the width of the score. Eliminates the need for shims, endless measuring, reassembling, testing and adjusting to obtain the required width.

  • Fully adjustable in increments of 0.1mm
  • Kerf adjusts from 2.8mm to 3.6mm
  • Available in 100mm and 120mm diameters with 15mm,
    20mm, 22mm and 3/4″ bores
  • Replacement blades available
  • Fits most machines including Altendorf® and SCM

Fits additional machines: Casolin Astra Top, Casadei Shark & Lazzari

Chamfered dial for SCM machine. Includes bushing #BEZ-015 from 22mm to 155mm

Specifications

(D) Diameter 120mm
Teeth 12x2
(d) Bore 22mm & 3/4
Kerf (B) (2.8-3.6mm)
Machine Fits most machines including Altendorf®, SCM, Casolin Astra Top, Casadei Shark & Lazzari
